BigFlag Large Steel Flagpole – 100x14 | Commercial-Grade

Product Description:

Overview

The BigFlag 100x14 Large Steel Flagpole is engineered to make a bold statement. Standing 100 feet tall with a 14-inch butt diameter, this commercial-grade steel flagpole offers unmatched durability and presence. Built for locations that demand visibility and strength—municipal centers, corporate campuses, schools, and patriotic landmarks—this giant flagpole is constructed from A-36 Carbon Steel and designed to fly flags up to 30x60 feet (flag sold separately).

This model features a manual internal hand crank winch system, ideal for reliable flag raising and lowering in high-wind or heavy-duty environments.

Key Specifications

• Material: A-36 Carbon Steel

• Exposed Height: 100 feet

• Butt Diameter: 14 inches

• Wall Thickness: 0.500 inches

• Flag Size Capacity: Up to 30x60 ft (flag not included)

• Sections: Ships in 4 tapered steel sections

• Wind Rating (Flagged): 90 mph

• Wind Rating (Unflagged): 130 mph

Engineering & Compliance

• Built to ANSI/NAAMM FP-1001-97 engineering standards

• Complies with local wind and ice load requirements nationwide

• Optional stamped engineering drawings and foundation specs available upon request

Construction & Finish

• Made with high-strength A-36 steel (36,000 PSI yield)

• Seamless steel concentric reducers for smooth, tapered profile

• Includes:

  • Corrugated steel foundation sleeve

  • Steel base plate

  • Lightning spike arrestor

• Surface prep: Full sandblast before coating

• Finish: Industrial-grade epoxy primer + gloss urethane topcoat for color retention and weather resistance

Winch System & Hardware

• Internal Hand Crank Winch System (manual)

• Heavy-Duty Revolving Truck Ball Assembly

• 1.25" stainless steel spindle

• 1/8" stainless aircraft cable

• Locking internal winch with removable handle

• Beaded retainer rings, counterweight, snaphooks, and connectors included

Warranty & Support

• Includes a 1-Year Limited Warranty on the shaft

• Contact us for details, installation support, or optional upgrades

Important Notes

• Flag not included (compatible with 30x60 ft nylon or polyester flags)

• Installation services available nationwide

• Due to steel pricing volatility, final price may vary—please call for current quote and financing options
