BigFlag Large Steel Flagpole – 200x42 | Motorized Winch

Product Description:

Overview

The BigFlag 200x42 Large Steel Flagpole is the ultimate symbol of scale, strength, and American pride. Towering at 200 feet with a 42-inch butt diameter, this is our largest commercial steel flagpole available. Designed to fly a 50x80 ft American flag (flag not included), it’s engineered to stand tall in extreme wind conditions and deliver an iconic statement.

Perfect for national landmarks, state capitols, military bases, stadiums, and the most prominent civic installations, this massive flagpole includes a motorized internal winch system for safe, powerful flag control.

Key Specifications

• Material: A-36 Carbon Steel

• Exposed Height: 200 feet

• Butt Diameter: 42 inches

• Wall Thickness: 0.5 inches

• Recommended Flag Size: 50x80 ft (flag not included)

• Shipping Sections: 6 precision-tapered steel sections

• Wind Rating (Flagged): 90 mph

• Wind Rating (Unflagged): 130 mph

Engineering & Compliance

• Meets ANSI/NAAMM FP-1001-97 structural design standards

• Built to exceed national wind and ice loading requirements

• Stamped engineering drawings and custom foundation specifications available upon request

Construction & Finish

• Made from high-strength A-36 Steel with a 36,000 PSI yield

• Seamless concentric steel reducers create a smooth tapered profile

• Includes:

  • Corrugated steel foundation sleeve

  • Oversized steel base plate

  • Lightning spike arrestor

  • Touch-up paint kit for long-term field care

• Finish system:

  • Sandblasted surface preparation

  • Chemically cured epoxy primer

  • Aliphatic urethane gloss enamel for maximum color retention and durability

Motorized Winch System & Hardware

• Heavy-Duty Internal Electric Winch

• Revolving truck ball assembly with 1.25" stainless steel spindle

• 1/8" stainless aircraft cable

• Locking internal winch with removable crank handle

• Includes full flag hardware: beaded retainer rings, counterweight, stainless snaphooks, and connecting links

Warranty & Support

• Backed by a 1-Year Limited Manufacturer Warranty (shaft only)

• Installation support, freight quotes, and custom engineering services available upon request

Important Notes

• Flag not included

• Steel pricing subject to change — contact us for a real-time quote

• All BigFlag poles are sandblasted, primed, and finished prior to shipping

• Freight, foundation design, and installation services are billed separately
